Worm Gear Screw Jacks 1T
13000.0 आईएनआर/टुकड़ा
उत्पाद विवरण:
- प्रॉडक्ट टाइप Worm Gear Screw Jack
- मटेरियल High-grade cast iron
- उठाने की क्षमता 1 Ton (1000 kg)
- हैंडल Manual or Motorized Operation
- वोल्टेज का सामना करें 1500V AC/minute
- एप्लीकेशन Industrial lifting and positioning
- इन्सुलेशन प्रतिरोध 100 M Min. at 500V DC
- Click to view more
X
मूल्य और मात्रा
- 1
- Trapezoidal Thread
- Grease Lubrication
- 25%
- Clockwise/Counter Clockwise
- IP54
- -20C to +80C
- 1500 rpm
- 24:1
- Yes
- Standard 150 mm (Customizable)
- 18 mm
- Flange Mounted
- 120 mm x 120 mm
- 24 mm
उत्पाद की विशेषताएं
- Manual or Motorized Operation
- 15 kg
- 100 M Min. at 500V DC
- Industrial lifting and positioning
- 1500V AC/minute
- High-grade cast iron
- 300 mm (retracted), 450 mm (extended)
- 1 Ton (1000 kg)
- Blue
- Worm Gear Screw Jack
- Trapezoidal Thread
- Grease Lubrication
- 25%
- Clockwise/Counter Clockwise
- IP54
- -20C to +80C
- 1500 rpm
- 24:1
- Yes
- Standard 150 mm (Customizable)
- 18 mm
- Flange Mounted
- 120 mm x 120 mm
- 24 mm
व्यापार सूचना
- हफ़्ता
उत्पाद विवरण
SFI Mechatronic Solutions Pvt. Ltd. SWJM Series Classic Jacks:
-
Precision Lifting with SWJM Series: Simran Flowtechs SWJM Series Classic Jacks provide smooth, accurate lifting for heavy-duty applications, ensuring reliable and consistent performance across various industrial environments.
-
Robust & Efficient Bevel Gear Design: Our SWJM Series is equipped with durable bevel gears for superior efficiency, enabling consistent operation even under the heaviest loads.
-
Compact & Versatile Solution: The SWJM Series Classic Jacks feature a space-saving design, making them perfect for tight installations while maintaining powerful load-handling capabilities.
-
Multi-Jack Synchronized Operation: With seamless multi-configuration options, SWJM Series Classic Jacks are ideal for synchronized lifting tasks that require precise control and coordination.
-
Customizable to Fit Your Needs: Simran Flowtech offers the SWJM Series Classic Jacks in various sizes and configurations to suit your unique load, speed, and operational demands.
-
Minimal Maintenance, Maximum Uptime: Built for durability and easy maintenance, SWJM Series jacks deliver continuous high performance, reducing downtime even in the toughest industrial conditions.
-
Safe & Reliable Operation: The SWJM Series is engineered with safety in mind, incorporating anti-backlash features and load-holding mechanisms, ensuring stable and secure lifting in critical operations.
Reliable Self-Locking Performance
The worm gear screw jack is designed with a self-locking trapezoidal thread, ensuring secure holding of loads without back driving. This critical feature makes it ideal for lifting and precise positioning in demanding environments, enhancing operator and equipment safety.
Customizable for Industrial Applications
While it comes with a standard 150 mm stroke length, this screw jack can be tailored to meet your specific requirements. The sturdy construction and flange mounting make it suitable for a wide range of industrial uses, from factory automation to material handling.
Durability and Safe Operation
Manufactured from high-grade cast iron and equipped with IP54 protection, the jack withstands harsh conditions and resists dust and splashes. With insulation resistance of at least 100 M at 500V DC and a withstand voltage of 1500V AC/minute, safety and durability are integral to its design.
FAQ's of Worm Gear Screw Jacks 1T:
Q: How does the self-locking mechanism work in the 1T worm gear screw jack?
A: The self-locking feature is achieved through the trapezoidal thread design, preventing the lift screw from descending under load unless operated. This ensures the load remains securely positioned, adding an extra safety layer in industrial environments.Q: What is the recommended process for installing the worm gear screw jack?
A: The jack is flange-mounted, so secure it to a flat, sturdy surface using compatible fasteners. Ensure proper alignment of the input shaft and lift screw before operation, and maintain adequate lubrication as specified.Q: When should I use manual versus motorized operation for this jack?
A: Manual operation is ideal for infrequent adjustments or lighter loads, whereas motorized operation is recommended for regular, repetitive lifting tasks or when handling the maximum load of 1 ton.Q: What are the benefits of the IP54 protection class in this screw jack?
A: IP54 protection safeguards the jack against dust ingress and water splashes, extending lifespan and maintaining consistent performance even in challenging industrial settings.Q: Where is this worm gear screw jack typically used?
A: It is used in various industrial applications including lifting platforms, conveyor systems, and machinery positioning, particularly where precise control and reliable load holding are required.Q: How can I customize the stroke length for my application?
A: You can request customization of the stroke length beyond the standard 150 mm by contacting the manufacturer or supplier during the order process. Customization ensures the jack fits your specific lifting or positioning requirements.Tell us about your requirement
